CÁMARA
Sensor De Imagen 1|2.8" progressive scan CMOS
Max. Resolución 2560 1440
Iluminación Mínima Color: 0.005 Lux @ (F1.5, AGC ON), B|W: 0.001 Lux@(F1.5, AGC ON), 0 Lux with IR
Velocidad De Obturación 1|1 s to 1|30000 s
Día Y Noche IR cut filter
Zoom 25x optical, 16x digital
Obturador Lento Yes
DORI
Detect (25px|m): 2046.9 m
Observe (63px|m): 812.3 m
Recognize (125px|m): 409.4 m
Identify (250px|m): 204.7 m
LENTE
Longitud Focal 4.8 mm to 120 mm
FOV
Horizontal field of view: 50.8 to 2.6 (wide-tele),
Vertical field of view: 29.4 to 1.5 (wide-tele),
Diagonal field of view:57.4 to 3 (wide-tele)
Enfoque Auto, semi-auto, manual
Apertura Max. F1.5
Velocidad Del Zoom Approx. 4.8 s
ILUMINADOR
Tipo De Luz Suplementaria IR
Rango De Luz Suplementaria IR Distance: up to 200 m
PTZ
Rango De Movimiento (Pan)360
Rango De Movimiento (Tilt)-15 to 90 (auto flip)
Velocidad De Movimiento Horizontal (Pan)Pan speed: configurable from 0.1 to 160|s; preset speed: 240|s
Velocidad De Vertical (Tilt)Tilt speed: configurable from 0.1 to 120|s, preset speed 200|s
Proportional Pan Yes
Preajustes 300
Congelación Preestablecida Yes
Escaneo De Patrulla 8 patrols, up to 32 presets for each patrol
Patrón De Escaneo 4 pattern scans
Acción Del Parque Preset, pattern scan, auto scan, tilt scan, random scan, frame scan, panorama scan
Posicionamiento 3D Yes
Pantalla De Estado De PTZ Yes
Tarea Programada Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
Memoria De Apagado Yes
VÍDEO
Main Stream
50 Hz: 25 fps (2560 1440, 1920 1080, 1280 960, 1280 720);
60 Hz: 30 fps (2560 1440, 1920 1080, 1280 960, 1280 720)
Sub-Stream
50 Hz: 25 fps (704 576, 640 480, 352 288);
60 Hz: 30 fps (704 480, 640 480, 352 240)
Third Stream
50 Hz: 25 fps (1920 1080, 1280 960, 1280 720, 704 576, 640 480, 352 288);
60 Hz: 30 fps (1920 1080, 1280 960, 1280 720, 704 480, 640 480, 352 240)
COMPRESIÓN DE VÍDEO
Main stream: H.265+|H.265|H.264+|H.264
Sub-stream: H.265|H.264|MJPEG
Third stream: H.265|H.264|MJPEG
Vídeo Bitrate 32 kbps to 16384 kbps
Tipo H.264 Baseline Profile|Main Profile|High Profile
Tipo H.265 Main Profile
Codificación De Video Escalable (SVC)H.264 and H.265 encoding
Región De Interés (ROI)8 fixed regions for each stream
AUDIO
Compresión De Audio G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM
Velocidad De Bits De Audio 64 Kbps (G.711)|16 Kbps (G.722.1)|16 Kbps (G.726)|32-192 Kbps (MP2L2)|16-64 Kbps (AAC)
Frecuencia De Muestreo De Audio 8 kHz|16 kHz|32 kHz|48 kHz
Filtro De Ruido Ambiental Yes
IMAGEN
Configuración De Imagen Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Interruptor Día|Noche Day, Night, Auto, Schedule
Wide Dynamic Range (WDR)120 dB
SNR> 52 dB
Desempañar Digital defog
Image Stabilization EIS
Mejora De La Imagen BLC, HLC, 3D DNR
Máscara De Privacidad 24 programmable polygon privacy masks, mask color or mosaic configurable
Enfoque Regional Yes
Exposición Regional Yes
INTERFAZ
Ethernet Interface1 RJ45 10M|100M self-adaptive Ethernet port
Almacenamiento A Bordo Built-in memory card slot, support microSD|SDHC|SDXC card, up to 256 GB
Altavoz Incorporado 1 built-in speaker with effective distance reaching max. 30 meters
Audio1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 kO 10%; 1 output (line out), line level, output impedance: 600 O
Alarma2 inputs, 1 output
Reiniciar Yes+D153:D182
