CÁMARA
Sensor De Imagen 1|1.8" Progressive Scan CMOS
Max. Resolución 2688 1520
ILUMINACIÓN MÍNIMA
Color: 0.0005 Lux @ (F1.2, AGC ON);
B|W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR
Tiempo De Obturación 1 s to 1|100,000 s
Día Y Noche
IR cut filter
Blue glass module to reduce ghost phenomenon
LENTE
FOCAL LENGTH & FOV
2.8 to 12 mm, horizontal FOV: 114.5 to 41.8, vertical FOV: 59.3 to 23.6, diagonal FOV: 141.1 to 48
8 to 32 mm, horizontal FOV: 42.5 to 15.1, vertical FOV: 23.3 to 8.64, diagonal FOV: 49.6 to 17.3
EnfoqueAuto,Semi-auto,Manual
Iris TypeP-iris
APERTURA
2.8 to 12 mm: F1.2 to F2.5
8 to 32 mm: F1.7 to F1.73
DORI
Wide:
2.8 to 12 mm: D (Detect): 60 m, O (Observe): 23.8 m, R (Recognize): 12 m, I (Identify): 6 m
8 to 32 mm: D (Detect): 150.3 m, O (Observe): 59.7 m, R (Recognize): 30.1 m, I (Identify): 15 m
Tele:
2.8 to 12 mm: D (Detect): 149 m, O (Observe): 59.1 m, R (Recognize): 29.8 m, I (Identify): 14.9 m
8 to 32 mm: D (Detect): 400 m, O (Observe): 158.7 m, R (Recognize): 80 m, I (Identify): 40 m
ILUMINADOR
Tipo De Luz SuplementariaIR
Rango De Luz Suplementaria
2.8 to 12 mm: 50 m
8 to 32 mm: 100 m
Luz De Suplemento Inteligente Yes
IR Wavelength 850 nm
VÍDEO
Main Stream
50 Hz:
25 fps (2688 1520, 2560 1440, 1920 1080, 1280 720)
50 fps (2560 1440, 1920 1080, 1280 720)
60 Hz:
30 fps (2688 1520, 2560 1440, 1920 1080, 1280 720)
60 fps (2560 1440, 1920 1080, 1280 720)
Sub-Stream
50 Hz: 25 fps (704 576, 640 480)
60 Hz: 30 fps (704 480, 640 480)
Third Stream
50 Hz: 25 fps (1920 1080, 1280 720, 704 576, 640 480)
60 Hz: 30 fps (1920 1080, 1280 720, 704 480, 640 480)
Fourth Stream
50 Hz: 25 fps (704 576, 640 480)
60 Hz: 30 fps (704 480, 640 480)
Fifth Stream
50 Hz: 25 fps (704 576, 640 480)
60 Hz: 30 fps (704 480, 640 480)
COMPRESIÓN DE VIDEO
Main stream: H.265+|H.265|H.264+|H.264,
Sub-stream: H.265|H.264|MJPEG,
Third stream: H.265|H.264,
Fourth stream: H.265|H.264|MJPEG,
Fifth stream: H.265|H.264|MJPEG
Vídeo Bitrate 32 Kbps to 8 Mbps
Tipo H.264B aseline Profile,Main Profile,High Profile
Tipo H.265 Main Profile
Bit Rate Control CBR,VBR
Codificación De Video Escalable (SVC)H.264 and H.265 encoding
Región De Interés (ROI)4 fixed regions for each stream
Recorte Objetivo Yes
E-PTZ Support Patrol and Auto Tracking settings
AUDIO
Tipo De Audio Mono sound
Compresión De Audio G.711|G.722.1|G.726|MP2L2|PCM|MP3|AAC-LC
Velocidad De Bits De Audio 64 Kbps (G.711ulaw|G.711alaw)|16 Kbps (G.722.1)|16 Kbps (G.726)|32 to 192 Kbps (MP2L2)|8 to 320 Kbps (MP3)|16 to 64 Kbps (AAC-LC)
Frecuencia De Muestreo De Audio 8 kHz|16 kHz|32 kHz|44.1 kHz|48 kHz
Filtro De Ruido Ambiental Yes
IMAGEN
Interruptor De Parámetros De Imagen Yes
Configuración De Imagen Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser
Interruptor Día|Noche Day,Night,Auto,Schedule,Alarm Trigger,Video Trigger
Wide Dynamic Range (WDR)140 dB
SNR= 52 dB
Mejora De La Imagen BLC,HLC,3D DNR,Distortion Correction,Defog
Superposición De Imagen LOGO picture can be overlaid on video with 128 128 24 bit bmp format.
Image Stabilization EIS
Máscara De Privacidad 8 programmable polygon privacy masks
INTERFAZ
Salida De Vídeo 1 Vp-p Composite Output (75 O|CVBS) (Only for debugging)
Ethernet Interface 1 RJ45 10 M|100 M|1000 M self-adaptive Ethernet port
On-Board Storage Built-in memory card slot, support microSD|microSDHC|microSDXC card, up to 1 TB
Audio With -Y: 1 input (line in), 1 output (line out), 3.5 mm connector
Alarma 2 inputs, 2 outputs (max. 24 VDC, 1 A)
RS-485 With -Y: 1 RS-485 (half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset Key Yes
Salida De Alimentación With -Y: 12 VDC, max. 100 mA
Wiegand-Y: 1 Wiegand (CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit)
